ZBLZGP WEIPU WS20 9-Pin IP67 Waterproof Aviation Connector, M20 Square Panel Mount, Metal Threaded Plug Socket, AC DC Electrical Power Signal Connector for Industrial LED Equipment
ℹ
Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.
•WEIPU WS20 Male Plug Female Square Socket Waterproof IP67 Aviation Power Electrical Wire Connector.
•WS20 Pins:2Pin;Contact Diameter: Φ2.5X2,Contact resistance: 1mΩ ;Wire Size: ≤4mm² /11 AWG;Rated Current / Voltage : 25A / AC 500V;Withstand Voltage : AC 1500V.
•Connection method :threaded connection.Shell material :zinc alloy (chrome-plated).Contact parts material:copper (gold-plated).
•WS20 series metal panel mount connector, mainly used in industrial automation power connectors, automotive, marine, high voltage, waterproof, anti-vibration.
•Electrical Power Connector Plug + Socket, Outdoor Waterproof IP67.Widely used in various machine tools, locomotives, electricity, post and telecommunications, communications, navigation, instrumentation, lighting systems, medical and oil exploration and other fields.
