flagProduct From USA
new | HINYSENO PCIe x8 Dual 25G SFP28 Fiber Port 25Gb Ethernet PCI Express x8 Network Cards Adapter with Mellanox ConnectX-4 LX Chipset
Brand : HINYSENO
new | HINYSENO PCIe x8 Dual 25G SFP28 Fiber Port 25Gb Ethernet PCI Express x8 Network Cards Adapter with Mellanox ConnectX-4 LX Chipset
Brand : HINYSENO
Product Specifications
Conditionnew
AsinB0BQYVPRTK
CategoryElectronics
SubcategoryNetwork Cards
ColorDual QSFP/ 25G / X-4
OriginUSA
BrandnameHINYSENO
Weight1
Warranty Description1 Year Warranty
Product Details
The PCIe x8 Mellanox ConnectX-4 LX Dual-Port 25G SFP adapter with 25Gb/s Ethernet connectivity addresses virtualized infrastructure challenges for today’s demanding market and applications.
Providing true hardware-based I/O isolation with unmatched scalability and efficiency, ConnectX-4 EN provides a cost-effective and flexible Ethernet adapter solution for Web2.0, cloud, data analytics, database, and storage platforms.
It provide a combination of 25G bandwidth, sub-microsecond latency and a 75 million packets per second message rate.
It include native hardware support for RDMA over Converged Ethernet(RoCE) ,Ethernet stateless offload engines, Overlay Networks, GPUDirect technology and Mellanox Multi-Host Technology.
Supports Operation Systems: FreeBSD, Linux5.x and above, VMware5.5/6.0/6.5/6.7, Windows server2008/2012/2016/2019, win7/win8/win8.1/win10 32 or 64bit
What's Inside The Box ?
HINYSENO PCIe x8 Mellanox Connectx-4 Dual-Port 25G SFP+ adapter
Product Description
Description
PCIe x8 Mellanox ConnectX-4 LX Dual-Port 25G SFP adapter with 25Gb/s Ethernet connectivity addresses virtualized infrastructure challenges for today’s demanding market and applications. Providing true hardware-based I/O isolation with unmatched scalability and efficiency, ConnectX-4 EN provides a cost-effective and flexible Ethernet adapter solution for Web2.0, cloud, data analytics, database, and storage platforms. It provide a combination of 25G bandwidth, sub-microsecond latency and a 75 million packets per second message rate. It include native hardware support for RDMA over Converged Ethernet(RoCE) ,Ethernet stateless offload engines, Overlay Networks, GPUDirect○R technology and Mellanox Multi-Host○R Technology.


Specification

  •     Compliant with PCI Express Specification Revision 3.0,1.1 and 2.0
  •     2.5,5.0, or 8.0GT/s link rate x8
  •     Auto-negotiates to x8, x4, x2, or x1
  •     Support for MSI/MSI-X mechanisms
  •     Supports dual-Port 25G,10G, or 1Gb/s SFP+
  •     IEEE802.3by,25G supporting all FEC modes
  •     IEEE802.3az Energy Efficient Ethernet
  •     IEEE802.3ap based auto-negotiation and KR startup
  •     Support Standards IEEE802.3ad, IEEE802.1ax, IEEE802.1Q, IEEE802.1P, IEEE802.1Qaz, IEEE802.1Qbb, IEEE802.1Qbg, IEEE1588V2
  •     Jumbo frame support 9.6KB
  •     Independent NC-SI SMBus interface
  •     Independent stand-by and wake-on-Lan signals
  •     Hardware-based reliable transport
  •     Collective operation offloads
  •     PeerDirect RDMA (aka GPUDirect communication acceleration)
  •     64/66 encoding
  •     Extended Reliable connected transport
  •     Dynamically connected transport
  •     RDMA over Converged Ethernet (RoCE)
  •     TCP/UDP/IP stateless offload
  •     LSO.LRO. checksum offload
  •     Hardware offload of encapsulation and decapsulation of NVGRE and VXLAN overlay networks
  •     SR-IOV, Multi-function, Enhanced QoS, VMware support
  •     SR-IOV up to 256 virtual functions
  •     SR-IOV up to 8 physical functions per port
  •     Guaranteed QoS for VMs
  •     OpenMPI, IBM PE, OSU MPI, Intel MPI protocol support
  •     NC-SI over MCTP over SMBus and NC-SI over MCTP over PCIe-Baseboard Management Controller interface
  •     Remote boot over Ethernet, iSCSI, PXE, and UEFI
  •     Supports Operation Systems: FreeBSD, Linux5.x and above, VMware5.5/6.0/6.5/6.7, Windows server2008/2012/2016/2019, win7/win8/win8.1/win10 32 or 64bit
Package content
    1 x PCIe x8 Mellanox Connectx-4 Dual-Port 25G SFP+ adapter
    1 x User’s Manual
    1 x CD Driver
    1 x Low profile bracket

System Requirements
  • FreeBSD, Linux , VMWare ESXi
  • Win-server2008 R2/ Win-server2012 R2/ Win-server2016/Win-server2019
  • Windows: 8/8.1/10 32/64bit
  • One available PCI Express x8/x16 slot
