✔Product Features: ✭ Equipped with ESP32-C3-MINI-1 module ✭Easy to use and flexible to expand ✭Most of the pins of the module on the board have been led out to the pin headers on both sides ✭ Easily connect a variety of peripherals via jumpers ✭ Very low power SoC with RISC-V 32-bit single-core processor ✭Supports IEEE 802.11b/g/n (2.4 GHz Wi-Fi) and Bluetooth 5 (LE) ✭The ESP32-C3 series chips with ultra-low power consumption are designed for Internet of Things (IoT) devices
✔Wi-Fi Features: .Support IEEE 802.11 b/g/n protocol .Supports 20 MHz and 40 MHz bandwidths in the 2.4 GHz band .Support 1T1R mode, data rate up to 150 Mbps .4x virtual Wi-Fi interface .Support Infrastructure BSS Station mode, SoftAP mode, Station + SoftAP mode, and Promiscuous mode at the same time Please note that when the ESP32-C3 series chip scans in Station mode, the SoftAP channel will change at the same time .Antenna Diversity .802.11 mc FTM .Support external power amplifier
✔Application areas include: Smart Home: Smart Lighting Industrial automation: industrial robots, mesh networking, human-machine interface, industrial bus applications Consumer electronics: smart watches, smart bracelets, OTT TV boxes, set-top box devices Wi-Fi speaker Smart agriculture: smart greenhouses, smart irrigation, agricultural robots Retail catering: POS systems Audio equipment: Network music player Universal low-power IoT sensor hub Universal low-power IoT data logger
✔Power Options: You can choose one of the following three power supply methods to power the ESP32-C3-DevKitM-1: ①Micro-USB interface power supply (default) ②5V and GND pin header power supply. ③3V3 and GND pin header power supply It is recommended to choose the first power supply method: Micro-USB interface power supply.
✔Required Hardware: ESP32-C3-DevKitM-1 development board USB 2.0 data cable (standard type A to Micro-B type) Computer (Windows, Linux, or macOS)
Product From USA
