𝟮𝟬𝟮𝟯 𝙐𝙥𝙜𝙧𝙖𝙙𝙚𝙙 Flame Rod Sensor lgniter 24V Replacements for Honeywell Q3400A1024/U Q3620,Q3480, Q3450,R42640-001 Used For SV9500M Valve

ℹ

Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.

•Fits Armstrong furnace models beginning with: UJ, GUK, GCK, GCJ, GHJ, GU93, GH90, 39708, 39800, 40019, 40020, 40414, 42213, 43235
•Length 30" . Voltage 24, Gas Type NG/LP, Includes Flame Rod, Mounting Clip and Hardware '
•Replaces Of Honeywell model Number 1009524, 1149856, 42640001, Q3400A, Q3400A1016, Q3400A1040, Q3450, Q3480, Q3620, SV9401, SV9402, SV9403, SV9500, SV9500M2603, SV9500M2674, SV9500M2682, SV9501, SV9501M2528, SV9502, SV9503, SV9600, SV9600H, SV9601, SV9602, AFN643, L43-724, 68012, IG9500, and MM643KX.
•Time to temperature (1800°F): 2.5 - 3 seconds @ 24 VAC. Voltage: 24 VAC. Amperage: 0.98 - 1.4 amps @ 24 VAC. Cold resistance: 4-6 Ohms @ 75°F +/- 10°F. 18 gauge copper high-temperature fiberglass insulated lead wires.
•Applications: furnaces, boilers, water heaters, unit heaters, and pool heaters. It is important to disconnect your appliance from the power supply before servicing.

From USA

NewTxdiyifu

𝟮𝟬𝟮𝟯 𝙐𝙥𝙜𝙧𝙖𝙙𝙚𝙙 Flame Rod Sensor lgniter 24V Replacements for Honeywell Q3400A1024/U Q3620,Q3480, Q3450,R42640-001 Used For SV9500M Valve

ℹ

Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.

•Fits Armstrong furnace models beginning with: UJ, GUK, GCK, GCJ, GHJ, GU93, GH90, 39708, 39800, 40019, 40020, 40414, 42213, 43235
•Length 30" . Voltage 24, Gas Type NG/LP, Includes Flame Rod, Mounting Clip and Hardware '
•Replaces Of Honeywell model Number 1009524, 1149856, 42640001, Q3400A, Q3400A1016, Q3400A1040, Q3450, Q3480, Q3620, SV9401, SV9402, SV9403, SV9500, SV9500M2603, SV9500M2674, SV9500M2682, SV9501, SV9501M2528, SV9502, SV9503, SV9600, SV9600H, SV9601, SV9602, AFN643, L43-724, 68012, IG9500, and MM643KX.
•Time to temperature (1800°F): 2.5 - 3 seconds @ 24 VAC. Voltage: 24 VAC. Amperage: 0.98 - 1.4 amps @ 24 VAC. Cold resistance: 4-6 Ohms @ 75°F +/- 10°F. 18 gauge copper high-temperature fiberglass insulated lead wires.
•Applications: furnaces, boilers, water heaters, unit heaters, and pool heaters. It is important to disconnect your appliance from the power supply before servicing.
